| Brand | Ubiquiti |
| Network Management Type | Ethernet In-Band |
| Primary Ports | Interfaces Networking: (24) 10/100/1000 RJ45 Ports (2) 1/10G SFP+ Ethernet Ports |
| Primary Port Speed | Universal Input: 100-240VAC/50-60 Hz USP RPS DC Input: 52VDC, 7.69A; 11.5VDC, 2.61A |
| POE | Total Available PoE 400W PoE Interfaces Ports 1-16 Ports 17-24 POE+ IEEE 802.3af/at, (pins 1, 2+; 3, 6-) 60W PoE++ IEEE 802.3af/at/bt (Pins 1, 2+; 3, 6-) (Pair A 1, 2+; 3, 6-) (Pair B 4 , 5+; 7, 😎 Max. PoE Wattage per Port by PSE 802.3at 802.3bt 32W 64W |
| Leds | LEDs System RJ45 Data Ports SFP+ Data Ports Status PoE; Speed/Link/Activity Link/Activity |
| Power | Power Method Universal Input USP RPS DC Input 100-240VAC/50-60 Hz 52VDC, 7.69A; 11.5VDC, 2.61A Power Supply AC/DC, Internal, 450W Supported Voltage Range 100 to 240VAC Max. Power Consumption (Excluding PoE Output) 50W |
| Features | ESD/EMP Protection Air: ± 16 kV, Contact: ± 12 kV Shock and Vibration : ETSI300-019-1.4 Standard Operating Temperature -5 to 40° C (23 to 104° F) Operating Humidity 10 to 90% Noncondensing Certifications CE, FCC, IC |
| Dimensions | 442.4 x 285.4 x 43.7 mm |
| Weight | Weight 4.30 kg (9.48 lb) With Rackmount Brackets: 4.39 kg (9.68 lb) |
| Warranty | 1 Year Limited Warranty |
