Brand Cisco |
|
| Forwarding Bandwidth | • Max:2.8Gbps |
| Switching Bandwidth | • Max:5.6Gbps |
| Hardware
|
• DRAM: 128 MB DDR2 without ECC
• Onboard flash memory: 160 MB |
| Alarm | • Alarm I/O: output connector on top panel of 4P2S and 8P2S, 1.0A@24VDC or 0.5A@48VDC |
| Power consumption | Without PoE 8.6W, with PoE 72-140.4W |
| Connectors and cabling
|
• 100BASE-FX MMF (2 km)—TBD with engineer input
• 10/100/1000BASE-T ports: RJ-45 connectors, 4-pair Category 5 UTP cabling |
| Dimensions (H x W x D)including DIN rail | 5.0”H x 1.8” W x 5.3”D (127mm H x 45.7mmW x 134mm D) |
| Software features | LLDP, Cisco CDP aware, MSTP, STP Portfast, ICMP Vlans, static IP, Trust Ingress DSCP, COS, Priority Port, port – security, IGMP querier, DHCP server SNMP v2/v3, SNMP traps, syslog, IGMP snooping, DHCP snooping, BPDU guard, Etherchannel, Alarms, PoE capability, Smartport Macro, SPAN/Port Mirroring, Strom Control, EtherNet/IP (EDS) |
| Safety Certifications
|
• UL/CSA 60950-1
• EN 60950-1 • CB to IEC 60950-1 (with country deviations) • NOM to NOM-019-SCF1 (through partners and distributors) • UL/CSA/IEC/EN 61010-2-201 • CE Marking |
| Hazardous Locations
|
• ANSI/ISA 12.12.01 (Class1, Div2 A-D)
• EN 60079-0, -15 ATEX certificate (Class 1, Zone2 A-D) • IEC 60079-0, 15 (report only) • UL 60079-0, 15 • CAN/CSA C22.2 No. 60079-0, -15 * Cabinet enclosure required |
| Shock and Vibration
|
• IEC 60068-2-27 (Operational Shock: 30G 11ms, half sine)
• IEC 60068-2-27 (Non-Operational Shock 65-80G, trapezoidal) • IEC 60068-2-6, IEC 60068-2-64 (Operational Vibration) • EC 60068-2-6, IEC 60068-2-64, IEC 60068-2-47 (Non-operational Vibration) |
| Humidity
|
• IEC 60068 -2-3
• IEC 60068-2-30 (Test Db) • Relative humidity: 5% to 95% non-condensing |
